Send InquiryStandard Model Tablet Press Machine
About Standard Model Tablet Press Machine
Features
- Three Piece Turret with SS 316 Die Plate
- Gravity feeding system
- Two Sided (Tunnel Type) Lifting Upper Track
- Hand Operated Lubrication pump"
Optional Features
- Turret with Electro-less Nickel Plating
- Two Layer (Bi-layer) Attachment (For 27 & 35 STN Only)
| MODELS | CPMD3B-27 | CPMB3B-27 | CPMB3B-35 | CPMB3B-45 |
|---|---|---|---|---|
| No. of Stations | 27 | 27 | 35 | 45 |
| Tooling | D | B | B | BB |
| Max. Pressure (Ton) | 10 | 6.5 | 6.5 | 6.5 |
| Max. Tablet Dia. (mm) | 25 | 16 | 16 | 11 |
| Max Output (Tablets/hr)* | 97,200 | 97,200 | 1,26,000 | 1,62,000 |
| Depth of Fill (mm) | 20 | 17 | 17 | 17 |
| Motor (kW /HP0 | 2.2 / 5.0 | 2.2 / 3.0 | 2.2 / 3.0 | 3.7 / 5.0 |
| Electric Supply | 415V, 3Ø, AC, 50HZ | |||
