Send InquiryMega Press Double Rotary Tablet Press Machine
About Mega Press Double Rotary Tablet Press Machine
Features
- Three Piece Turret with SS 316 Die Plate
- Main Motor with ACVFD and Electro Magnetic Clutch
- Force Feeder with ACVFD
- Upper Guard interlocking
- 3 Type of Filling Cams
- Auto Lubrication Arrangement for centralized lubrication
- Compression Force for Main Roll by Hydraulic Power Pack
- Front and easy outside controls for machine & tablet parameters"
Optional Features
- PLC Touch Control System
- Two Layer (Bi-Layer) Attachment
- Gravity Feed Frame
| MODELS | CPMD-37 | CPMB-45 | CPMBB-55 | CPMBB-61 |
|---|---|---|---|---|
| No. of Stations | 37 | 45 | 55 | 61 |
| Tooling | D | B | BB | BB |
| Max. Output (Tab/hr)* | 222,000 | 324,000 | 396,000 | 439,200 |
| Max. Pressure | 10 Ton | 6.5 Ton | 6.5 Ton | 6.5 Ton |
| Max. Tablet Dia | 25 mm | 16 mm | 11 mm | 11 mm |
| Max. Depth of Fill | 20 mm | 17 mm | 17 mm | 17 mm |
| Main Motor | 7.5 HP | 7.5 HP | 7.5 HP | 7.5 HP |
| Force Feeder Motor | 0.5 HP | 0.5 HP | 0.5 HP | 0.5 HP |
| Electrical supply** | 10 HP, 3, AC | 10 HP, 3, AC | 10 HP, 3, AC | 10 HP, 3, AC |
