Send InquiryCPEB4 Double Rotary Tablet Press Machine
About CPEB4 Double Rotary Tablet Press Machine
Features
- Three Piece Turret with SS 316 Die Plate
- Upper Guard interlocking
- Upper Punch Penetration
- Main Motor with ACVFD and Electro-Magnetic Clutch
- Auto Lubrication Arrangement for centralized lubrication"
Optional Features
- Force Feeder Arrangement
- Two Layer (Bi-layer) Attachment
- PLC with HMI Touch Control System
- Effervescent tablet spray system for Lower Punch tip lubrication
| MODELS | CPEB4-27 | CPEB4-27 | CPEB4-35 | CPEB4-45 |
|---|---|---|---|---|
| No. of Stations | 27 | 27 | 35 | 45 |
| Tooling | D | B | B | BB |
| Max. Output (Tab/hr)* | 136,080 | 136,080 | 176,400 | 226,800 |
| Max. Pressure | 10 Ton | 6.5 Ton | 6.5 Ton | 6.5 Ton |
| Max. Tablet Dia | 25 mm | 16 mm | 16 mm | 11 mm |
| Max. Depth of Fill | 20 mm | 17 mm | 17 mm | 17 mm |
| Electrical supply** | 5 HP, 3, AC | 3 HP, 3, AC | 3 HP, 3, AC | 5 HP, 3, AC |
