Send InquiryPilot Press Premium machine
Pilot Press Premium machine Trade Information
- Main Domestic Market
- All India
About Pilot Press Premium machine
Features
- Three Piece Turret with SS 316 Die Plate
- Main Motor with ACVFD
- Gravity Feed Frame
- Upper Guard interlocking
- Upper Punch Penetration
- Dust Nozzle with Clamp"
Optional Features
- PLC with HMI Touch Control System
- 10 STN Combination Tooling (5D + 5B)
- Force Feeder with ACVFD
- Pre Compression Arrangement
| MODELS | PP- I D | PP- I B | PP- II D | PP- II B |
|---|---|---|---|---|
| No of Stations | 10 | 10 | 10 | 10 |
| Tooling | “D" | “B" | “D" | “B" |
| Max. Output (Tab/hr)* | 25,200 | 25,200 | 25,200 | 25,200 |
| Max. Operating Load | 4 Ton | 4 Ton | 4 Ton | 4 Ton |
| Max. Pre-comp. Load | - | - | 1 Ton | 1 Ton |
| Max. Tablet Dia | 23 mm | 16 mm | 23 mm | 16 mm |
| Depth of Fill | 20 mm | 17mm | 20 mm | 17 mm |
| Main Electric Motor | 2HP | 2HP | 2HP | 2HP |
| Feeder Electric Motor | 0.25HP | 0.25HP | ||
| Electrical supply** | 2 HP, 1Ø, AC | 2 HP, 1Ø, AC | 2.5 HP, 1Ø, AC | 2 HP, 1Ø, AC |
