Send InquiryOscillating Granulator
About Oscillating Granulator
| MODELS | CPMHG - 500 |
|---|---|
| Output (Kg / Hr.)* | 100 to 500 |
| Motor (kW/HP) | 1.5 / 2 |
| Hopper Capacity (Liter) | 33 |
| Screen Size (mm) | 490 W x 500 L |
| Stirrer Size (mm) | Ø 120 x 467 L |
| Oscillation (Per Minute) | 180 |
| Charging Height (mm) | 1345 (± 10mm) |
| Discharging Height (mm) | 802 (± 10mm) |
| Overall Dimension (L x B x H) (mm) | 900 x 1410 x 1370 (± 10mm) |
| Net Weight (Kgs.) Approx. | 400 |
| Gross Weight (Kgs.) Approx. | 550 |
| Power Supply | 1.5 kW / 2 HP, 415 V, 3Ø, AC, 50Hz |
