Product Description

Features

Uniform Drying with reducing Drying time
AHU with Double skinned & insulated (Inner side SS 304, Outer GI - Powder Coated)
Product Container with Trolley & Positive Earthing
Quick Dismantling of Dutch Sieve & Perforated Sheet at the Product container
Inflatable gaskets for Product Bowl & Filter Bag
Pneumatic rod less cylinder for Bag Lifting & Lowering (on side leg)
Operation Panel with PLC & 4" HMI
Pneumatic On / Off dampers at inlet & exhaust
Explosionrupture flap to the rear of the machine"

Optional Features

CPMFBD MODELS	15	30	60	120	200	300	400	500	600
Container Gross Vol Ltr.	46	71	142	280	475	650	870	1055	1350
Max. Batch Capacity (0.5 bd) kg*	0 - 15	20 - 30	40 - 60	80 - 120	160 - 200	200 - 300	300 - 400	400 - 500	500 - 600
Blower Motor HP**	7.5	7.5	10	20	25	30	40	50	50
Air Flow (CFM) + 10%	430	706	1060	1880	2590	3235	3825	4000	4705
Steam Pressure (kg/cm²)	-	-	-	-	-	-	-	-	-
Steam Consumption (kg/hr)	30	50	80	140	216	250	288	344	384
Electric Heater (kW)	18	20	36	60	N.A.	N.A.	N.A.	N.A.	N.A.
Compressed Air Pressure (bar)	8
Drying Temp (°C)	35-80
Electrical Supply**	415V ± 10%, AC, 3Ø, 50 HZ
